YK7340
REFNE
Min. root diameter
φ30
Max. tip dia.(external tooth)
φ400mm
No.of teeth
≥6（not undercutting gear）
Module
1～14mm
Max. tooth width（spur gear）
400mm
Helix angle
±45°
Distance between center of headstock and tailstock
350～765mm
Max. radial displacement of wheelhead
360mm
Max. axial displacement of wheelhead
650mm
Center distance between grinding wheel and center
35～360mm
Speed of grinding wheel
3000～6000rpm
Speed of dressing
1500～5000rpm
CNC axes of the machine
Axial moving axis of front worktable along workpiece-Z axis
Radial feeding axis of column along workpiece-X axis
Axial moving axis of grinding wheel-Y axis
Rotary axis of headstock-C axis
Rotary axis of grinding wheel pallet-A axis
Rotary axis of grinding wheel-S axis
Rotary axis of diamond roller-S1 axis
Axes in simultaneous motion X axis, Z axis, C axis.
