CK5120
Refine
The CK5120 Low Cost Automatic CNC Vertical Lathe is tailored to deliver cost-effective automation for mid-sized workpiece processing, making it an ideal solution for small-to-medium enterprises looking to balance productivity and budget. It features a 4-jaw manual chuck with rapid clamping mechanisms to reduce workpiece setup time, paired with an 8-station automatic tool changer that minimizes idle time between operations—improving overall productivity by up to 40% compared to manual lathes. Powered by a 18.5-30kW AC servo motor with high torque output at low speeds, it ensures efficient material removal even for tough materials like cast iron and alloy steel. The machine’s compact footprint optimizes workshop space utilization, while its enclosed splash guard protects operators from coolant and chip splatter.
Automotive: Producing brake discs with precise friction surfaces, transmission shafts requiring tight concentricity, and engine blocks with multiple bored holes.
Agriculture: Manufacturing tractor components such as axle housings and gear carriers, as well as irrigation system parts like large-diameter valve bodies.
General Manufacturing: Fabricating valves with precise sealing faces, flanges with standardized bolt hole patterns, and couplings for power transmission systems.
Its low maintenance costs—thanks to easily accessible components and durable wear parts—and high energy efficiency (with automatic power-saving mode during idle periods) make it particularly suitable for small-to-medium enterprises (SMEs) aiming to maximize return on investment.
Product Parameters
Specification | Unit | CK5110 | CK5112 | CK5116 | CK5120 | CK5123 | CK5126 |
Max dia | mm | 1000 | 1250 | 1600 | 2000 | 2300 | 2600 |
Table dia | mm | 900 | 1000 | 1400 | 1800 | 2000 | 2300 |
Max workpiece height | mm | 800 | 1000 | 1000/1200 | 1200 | 1200 | 1350 |
Max workpiece weight | t | 2 | 3.5 | 5 | 8 | 8 | 10 |
Max torque of table | KN.m | 20 | 25 | 30 | 40 | 40 | 45 |
Table rotate speed range (4gear stepless) | r/min | 1-250 | 1-200 | 1-160 | 1-100 | 1-80 | 1-63 |
Max cutting force of the vertical holder | KN | 20 | 20 | 25 | 25 | 25 | 30 |
Tool rest feed range | mm/min | 0.1-500 | 0.1-500 | 0.1-500 | 0.1-500 | 0.1-500 | 0.1-500 |
Tool rest feed level(ungraded) | grade | stepless | stepless | stepless | stepless | stepless | stepless |
Horizontal travel of rail head | mm | 670 | 700 | 915 | 1050 | 1250 | 1450 |
Ram travel of rail head | mm | 650 | 650 | 800 | 800 | 800 | 800 |
Crossbeam travel | mm | 650 | 650 | 850 | 900 | 900 | 950 |
Fast moving speed of tool heads | mm/min | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 |
Beam lift speed | mm/min | 440 | 440 | 440 | 440 | 440 | 440 |
Q: Is the CK5120 compatible with CAD/CAM software?
A: Yes, it supports G-code programming and seamlessly integrates with popular CAD/CAM software like SolidWorks, Mastercam, and AutoCAD. Our technical team provides free initial setup assistance for software integration.
Q: What is the power consumption during operation?
A: The machine consumes 15-20kW under full load. It also features an energy-saving mode that reduces power consumption by up to 30% during idle periods, automatically activating after 5 minutes of inactivity.
Q: Can I upgrade the CNC system later?
A: Yes, retrofitting to higher-end systems (e.g., Siemens 840D) is possible. Our engineering team can assess compatibility and perform the upgrade, including hardware replacement and software configuration, typically within 3-5 working days.
 |  |
 |  |
